rk3036.dtsi (21835B)
1// SPDX-License-Identifier: (GPL-2.0+ OR MIT) 2 3#include <dt-bindings/gpio/gpio.h> 4#include <dt-bindings/interrupt-controller/irq.h> 5#include <dt-bindings/interrupt-controller/arm-gic.h> 6#include <dt-bindings/pinctrl/rockchip.h> 7#include <dt-bindings/clock/rk3036-cru.h> 8#include <dt-bindings/soc/rockchip,boot-mode.h> 9#include <dt-bindings/power/rk3036-power.h> 10 11/ { 12 #address-cells = <1>; 13 #size-cells = <1>; 14 15 compatible = "rockchip,rk3036"; 16 17 interrupt-parent = <&gic>; 18 19 aliases { 20 i2c0 = &i2c0; 21 i2c1 = &i2c1; 22 i2c2 = &i2c2; 23 mshc0 = &emmc; 24 mshc1 = &sdmmc; 25 mshc2 = &sdio; 26 serial0 = &uart0; 27 serial1 = &uart1; 28 serial2 = &uart2; 29 spi = &spi; 30 }; 31 32 cpus { 33 #address-cells = <1>; 34 #size-cells = <0>; 35 enable-method = "rockchip,rk3036-smp"; 36 37 cpu0: cpu@f00 { 38 device_type = "cpu"; 39 compatible = "arm,cortex-a7"; 40 reg = <0xf00>; 41 resets = <&cru SRST_CORE0>; 42 operating-points = < 43 /* KHz uV */ 44 816000 1000000 45 >; 46 clock-latency = <40000>; 47 clocks = <&cru ARMCLK>; 48 }; 49 50 cpu1: cpu@f01 { 51 device_type = "cpu"; 52 compatible = "arm,cortex-a7"; 53 reg = <0xf01>; 54 resets = <&cru SRST_CORE1>; 55 }; 56 }; 57 58 arm-pmu { 59 compatible = "arm,cortex-a7-pmu"; 60 interrupts = <GIC_SPI 76 IRQ_TYPE_LEVEL_HIGH>, 61 <GIC_SPI 77 IRQ_TYPE_LEVEL_HIGH>; 62 interrupt-affinity = <&cpu0>, <&cpu1>; 63 }; 64 65 display-subsystem { 66 compatible = "rockchip,display-subsystem"; 67 ports = <&vop_out>; 68 }; 69 70 timer { 71 compatible = "arm,armv7-timer"; 72 arm,cpu-registers-not-fw-configured; 73 interrupts = <GIC_PPI 13 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_HIGH)>, 74 <GIC_PPI 14 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_HIGH)>, 75 <GIC_PPI 11 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_HIGH)>, 76 <GIC_PPI 10 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_HIGH)>; 77 clock-frequency = <24000000>; 78 }; 79 80 xin24m: oscillator { 81 compatible = "fixed-clock"; 82 clock-frequency = <24000000>; 83 clock-output-names = "xin24m"; 84 #clock-cells = <0>; 85 }; 86 87 bus_intmem: sram@10080000 { 88 compatible = "mmio-sram"; 89 reg = <0x10080000 0x2000>; 90 #address-cells = <1>; 91 #size-cells = <1>; 92 ranges = <0 0x10080000 0x2000>; 93 94 smp-sram@0 { 95 compatible = "rockchip,rk3066-smp-sram"; 96 reg = <0x00 0x10>; 97 }; 98 }; 99 100 gpu: gpu@10090000 { 101 compatible = "rockchip,rk3036-mali", "arm,mali-400"; 102 reg = <0x10090000 0x10000>; 103 interrupts = <GIC_SPI 3 IRQ_TYPE_LEVEL_HIGH>, 104 <GIC_SPI 4 IRQ_TYPE_LEVEL_HIGH>, 105 <GIC_SPI 5 IRQ_TYPE_LEVEL_HIGH>, 106 <GIC_SPI 4 IRQ_TYPE_LEVEL_HIGH>; 107 interrupt-names = "gp", 108 "gpmmu", 109 "pp0", 110 "ppmmu0"; 111 assigned-clocks = <&cru SCLK_GPU>; 112 assigned-clock-rates = <100000000>; 113 clocks = <&cru SCLK_GPU>, <&cru SCLK_GPU>; 114 clock-names = "bus", "core"; 115 power-domains = <&power RK3036_PD_GPU>; 116 resets = <&cru SRST_GPU>; 117 status = "disabled"; 118 }; 119 120 vpu: video-codec@10108000 { 121 compatible = "rockchip,rk3036-vpu"; 122 reg = <0x10108000 0x800>; 123 interrupts = <GIC_SPI 7 IRQ_TYPE_LEVEL_HIGH>; 124 interrupt-names = "vdpu"; 125 clocks = <&cru ACLK_VCODEC>, <&cru HCLK_VCODEC>; 126 clock-names = "aclk", "hclk"; 127 iommus = <&vpu_mmu>; 128 power-domains = <&power RK3036_PD_VPU>; 129 }; 130 131 vpu_mmu: iommu@10108800 { 132 compatible = "rockchip,iommu"; 133 reg = <0x10108800 0x100>; 134 interrupts = <GIC_SPI 55 IRQ_TYPE_LEVEL_HIGH>; 135 clocks = <&cru ACLK_VCODEC>, <&cru HCLK_VCODEC>; 136 clock-names = "aclk", "iface"; 137 power-domains = <&power RK3036_PD_VPU>; 138 #iommu-cells = <0>; 139 }; 140 141 vop: vop@10118000 { 142 compatible = "rockchip,rk3036-vop"; 143 reg = <0x10118000 0x19c>; 144 interrupts = <GIC_SPI 43 IRQ_TYPE_LEVEL_HIGH>; 145 clocks = <&cru ACLK_LCDC>, <&cru SCLK_LCDC>, <&cru HCLK_LCDC>; 146 clock-names = "aclk_vop", "dclk_vop", "hclk_vop"; 147 resets = <&cru SRST_LCDC1_A>, <&cru SRST_LCDC1_H>, <&cru SRST_LCDC1_D>; 148 reset-names = "axi", "ahb", "dclk"; 149 iommus = <&vop_mmu>; 150 power-domains = <&power RK3036_PD_VIO>; 151 status = "disabled"; 152 153 vop_out: port { 154 #address-cells = <1>; 155 #size-cells = <0>; 156 vop_out_hdmi: endpoint@0 { 157 reg = <0>; 158 remote-endpoint = <&hdmi_in_vop>; 159 }; 160 }; 161 }; 162 163 vop_mmu: iommu@10118300 { 164 compatible = "rockchip,iommu"; 165 reg = <0x10118300 0x100>; 166 interrupts = <GIC_SPI 43 IRQ_TYPE_LEVEL_HIGH>; 167 clocks = <&cru ACLK_LCDC>, <&cru HCLK_LCDC>; 168 clock-names = "aclk", "iface"; 169 power-domains = <&power RK3036_PD_VIO>; 170 #iommu-cells = <0>; 171 status = "disabled"; 172 }; 173 174 qos_gpu: qos@1012d000 { 175 compatible = "rockchip,rk3036-qos", "syscon"; 176 reg = <0x1012d000 0x20>; 177 }; 178 179 qos_vpu: qos@1012e000 { 180 compatible = "rockchip,rk3036-qos", "syscon"; 181 reg = <0x1012e000 0x20>; 182 }; 183 184 qos_vio: qos@1012f000 { 185 compatible = "rockchip,rk3036-qos", "syscon"; 186 reg = <0x1012f000 0x20>; 187 }; 188 189 gic: interrupt-controller@10139000 { 190 compatible = "arm,gic-400"; 191 interrupt-controller; 192 #interrupt-cells = <3>; 193 #address-cells = <0>; 194 195 reg = <0x10139000 0x1000>, 196 <0x1013a000 0x2000>, 197 <0x1013c000 0x2000>, 198 <0x1013e000 0x2000>; 199 interrupts = <GIC_PPI 9 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_HIGH)>; 200 }; 201 202 usb_otg: usb@10180000 { 203 compatible = "rockchip,rk3036-usb", "rockchip,rk3066-usb", 204 "snps,dwc2"; 205 reg = <0x10180000 0x40000>; 206 interrupts = <GIC_SPI 10 IRQ_TYPE_LEVEL_HIGH>; 207 clocks = <&cru HCLK_OTG0>; 208 clock-names = "otg"; 209 dr_mode = "otg"; 210 g-np-tx-fifo-size = <16>; 211 g-rx-fifo-size = <275>; 212 g-tx-fifo-size = <256 128 128 64 64 32>; 213 status = "disabled"; 214 }; 215 216 usb_host: usb@101c0000 { 217 compatible = "rockchip,rk3036-usb", "rockchip,rk3066-usb", 218 "snps,dwc2"; 219 reg = <0x101c0000 0x40000>; 220 interrupts = <GIC_SPI 11 IRQ_TYPE_LEVEL_HIGH>; 221 clocks = <&cru HCLK_OTG1>; 222 clock-names = "otg"; 223 dr_mode = "host"; 224 status = "disabled"; 225 }; 226 227 emac: ethernet@10200000 { 228 compatible = "rockchip,rk3036-emac", "snps,arc-emac"; 229 reg = <0x10200000 0x4000>; 230 interrupts = <GIC_SPI 8 IRQ_TYPE_LEVEL_HIGH>; 231 #address-cells = <1>; 232 #size-cells = <0>; 233 rockchip,grf = <&grf>; 234 clocks = <&cru HCLK_MAC>, <&cru SCLK_MACREF>, <&cru SCLK_MAC>; 235 clock-names = "hclk", "macref", "macclk"; 236 /* 237 * Fix the emac parent clock is DPLL instead of APLL. 238 * since that will cause some unstable things if the cpufreq 239 * is working. (e.g: the accurate 50MHz what mac_ref need) 240 */ 241 assigned-clocks = <&cru SCLK_MACPLL>; 242 assigned-clock-parents = <&cru PLL_DPLL>; 243 max-speed = <100>; 244 phy-mode = "rmii"; 245 status = "disabled"; 246 }; 247 248 sdmmc: mmc@10214000 { 249 compatible = "rockchip,rk3036-dw-mshc", "rockchip,rk3288-dw-mshc"; 250 reg = <0x10214000 0x4000>; 251 clock-frequency = <37500000>; 252 max-frequency = <37500000>; 253 clocks = <&cru HCLK_SDMMC>, <&cru SCLK_SDMMC>; 254 clock-names = "biu", "ciu"; 255 fifo-depth = <0x100>; 256 interrupts = <GIC_SPI 14 IRQ_TYPE_LEVEL_HIGH>; 257 resets = <&cru SRST_MMC0>; 258 reset-names = "reset"; 259 status = "disabled"; 260 }; 261 262 sdio: mmc@10218000 { 263 compatible = "rockchip,rk3036-dw-mshc", "rockchip,rk3288-dw-mshc"; 264 reg = <0x10218000 0x4000>; 265 max-frequency = <37500000>; 266 clocks = <&cru HCLK_SDIO>, <&cru SCLK_SDIO>, 267 <&cru SCLK_SDIO_DRV>, <&cru SCLK_SDIO_SAMPLE>; 268 clock-names = "biu", "ciu", "ciu-drive", "ciu-sample"; 269 fifo-depth = <0x100>; 270 interrupts = <GIC_SPI 15 IRQ_TYPE_LEVEL_HIGH>; 271 resets = <&cru SRST_SDIO>; 272 reset-names = "reset"; 273 status = "disabled"; 274 }; 275 276 emmc: mmc@1021c000 { 277 compatible = "rockchip,rk3036-dw-mshc", "rockchip,rk3288-dw-mshc"; 278 reg = <0x1021c000 0x4000>; 279 interrupts = <GIC_SPI 16 IRQ_TYPE_LEVEL_HIGH>; 280 bus-width = <8>; 281 cap-mmc-highspeed; 282 clock-frequency = <37500000>; 283 max-frequency = <37500000>; 284 clocks = <&cru HCLK_EMMC>, <&cru SCLK_EMMC>, 285 <&cru SCLK_EMMC_DRV>, <&cru SCLK_EMMC_SAMPLE>; 286 clock-names = "biu", "ciu", "ciu-drive", "ciu-sample"; 287 rockchip,default-sample-phase = <158>; 288 disable-wp; 289 dmas = <&pdma 12>; 290 dma-names = "rx-tx"; 291 fifo-depth = <0x100>; 292 mmc-ddr-1_8v; 293 non-removable; 294 pinctrl-names = "default"; 295 pinctrl-0 = <&emmc_clk &emmc_cmd &emmc_bus8>; 296 resets = <&cru SRST_EMMC>; 297 reset-names = "reset"; 298 status = "disabled"; 299 }; 300 301 i2s: i2s@10220000 { 302 compatible = "rockchip,rk3036-i2s", "rockchip,rk3066-i2s"; 303 reg = <0x10220000 0x4000>; 304 interrupts = <GIC_SPI 51 IRQ_TYPE_LEVEL_HIGH>; 305 clock-names = "i2s_clk", "i2s_hclk"; 306 clocks = <&cru SCLK_I2S>, <&cru HCLK_I2S>; 307 dmas = <&pdma 0>, <&pdma 1>; 308 dma-names = "tx", "rx"; 309 pinctrl-names = "default"; 310 pinctrl-0 = <&i2s_bus>; 311 #sound-dai-cells = <0>; 312 status = "disabled"; 313 }; 314 315 nfc: nand-controller@10500000 { 316 compatible = "rockchip,rk3036-nfc", 317 "rockchip,rk2928-nfc"; 318 reg = <0x10500000 0x4000>; 319 interrupts = <GIC_SPI 18 IRQ_TYPE_LEVEL_HIGH>; 320 clocks = <&cru HCLK_NANDC>, <&cru SCLK_NANDC>; 321 clock-names = "ahb", "nfc"; 322 assigned-clocks = <&cru SCLK_NANDC>; 323 assigned-clock-rates = <150000000>; 324 pinctrl-0 = <&flash_ale &flash_bus8 &flash_cle &flash_csn0 325 &flash_rdn &flash_rdy &flash_wrn>; 326 pinctrl-names = "default"; 327 status = "disabled"; 328 }; 329 330 cru: clock-controller@20000000 { 331 compatible = "rockchip,rk3036-cru"; 332 reg = <0x20000000 0x1000>; 333 clocks = <&xin24m>; 334 clock-names = "xin24m"; 335 rockchip,grf = <&grf>; 336 #clock-cells = <1>; 337 #reset-cells = <1>; 338 assigned-clocks = <&cru PLL_GPLL>; 339 assigned-clock-rates = <594000000>; 340 }; 341 342 grf: syscon@20008000 { 343 compatible = "rockchip,rk3036-grf", "syscon", "simple-mfd"; 344 reg = <0x20008000 0x1000>; 345 346 power: power-controller { 347 compatible = "rockchip,rk3036-power-controller"; 348 #power-domain-cells = <1>; 349 #address-cells = <1>; 350 #size-cells = <0>; 351 352 power-domain@RK3036_PD_VIO { 353 reg = <RK3036_PD_VIO>; 354 clocks = <&cru ACLK_LCDC>, 355 <&cru HCLK_LCDC>, 356 <&cru SCLK_LCDC>; 357 pm_qos = <&qos_vio>; 358 #power-domain-cells = <0>; 359 }; 360 361 power-domain@RK3036_PD_VPU { 362 reg = <RK3036_PD_VPU>; 363 clocks = <&cru ACLK_VCODEC>, 364 <&cru HCLK_VCODEC>; 365 pm_qos = <&qos_vpu>; 366 #power-domain-cells = <0>; 367 }; 368 369 power-domain@RK3036_PD_GPU { 370 reg = <RK3036_PD_GPU>; 371 clocks = <&cru SCLK_GPU>; 372 pm_qos = <&qos_gpu>; 373 #power-domain-cells = <0>; 374 }; 375 }; 376 377 reboot-mode { 378 compatible = "syscon-reboot-mode"; 379 offset = <0x1d8>; 380 mode-normal = <BOOT_NORMAL>; 381 mode-recovery = <BOOT_RECOVERY>; 382 mode-bootloader = <BOOT_FASTBOOT>; 383 mode-loader = <BOOT_BL_DOWNLOAD>; 384 }; 385 }; 386 387 acodec: acodec-ana@20030000 { 388 compatible = "rk3036-codec"; 389 reg = <0x20030000 0x4000>; 390 rockchip,grf = <&grf>; 391 clock-names = "acodec_pclk"; 392 clocks = <&cru PCLK_ACODEC>; 393 status = "disabled"; 394 }; 395 396 hdmi: hdmi@20034000 { 397 compatible = "rockchip,rk3036-inno-hdmi"; 398 reg = <0x20034000 0x4000>; 399 interrupts = <GIC_SPI 45 IRQ_TYPE_LEVEL_HIGH>; 400 clocks = <&cru PCLK_HDMI>; 401 clock-names = "pclk"; 402 rockchip,grf = <&grf>; 403 pinctrl-names = "default"; 404 pinctrl-0 = <&hdmi_ctl>; 405 status = "disabled"; 406 407 hdmi_in: port { 408 #address-cells = <1>; 409 #size-cells = <0>; 410 hdmi_in_vop: endpoint@0 { 411 reg = <0>; 412 remote-endpoint = <&vop_out_hdmi>; 413 }; 414 }; 415 }; 416 417 timer: timer@20044000 { 418 compatible = "rockchip,rk3036-timer", "rockchip,rk3288-timer"; 419 reg = <0x20044000 0x20>; 420 interrupts = <GIC_SPI 28 IRQ_TYPE_LEVEL_HIGH>; 421 clocks = <&cru PCLK_TIMER>, <&xin24m>; 422 clock-names = "pclk", "timer"; 423 }; 424 425 pwm0: pwm@20050000 { 426 compatible = "rockchip,rk3036-pwm", "rockchip,rk2928-pwm"; 427 reg = <0x20050000 0x10>; 428 #pwm-cells = <3>; 429 clocks = <&cru PCLK_PWM>; 430 pinctrl-names = "default"; 431 pinctrl-0 = <&pwm0_pin>; 432 status = "disabled"; 433 }; 434 435 pwm1: pwm@20050010 { 436 compatible = "rockchip,rk3036-pwm", "rockchip,rk2928-pwm"; 437 reg = <0x20050010 0x10>; 438 #pwm-cells = <3>; 439 clocks = <&cru PCLK_PWM>; 440 pinctrl-names = "default"; 441 pinctrl-0 = <&pwm1_pin>; 442 status = "disabled"; 443 }; 444 445 pwm2: pwm@20050020 { 446 compatible = "rockchip,rk3036-pwm", "rockchip,rk2928-pwm"; 447 reg = <0x20050020 0x10>; 448 #pwm-cells = <3>; 449 clocks = <&cru PCLK_PWM>; 450 pinctrl-names = "default"; 451 pinctrl-0 = <&pwm2_pin>; 452 status = "disabled"; 453 }; 454 455 pwm3: pwm@20050030 { 456 compatible = "rockchip,rk3036-pwm", "rockchip,rk2928-pwm"; 457 reg = <0x20050030 0x10>; 458 #pwm-cells = <2>; 459 clocks = <&cru PCLK_PWM>; 460 pinctrl-names = "default"; 461 pinctrl-0 = <&pwm3_pin>; 462 status = "disabled"; 463 }; 464 465 i2c1: i2c@20056000 { 466 compatible = "rockchip,rk3036-i2c", "rockchip,rk3288-i2c"; 467 reg = <0x20056000 0x1000>; 468 interrupts = <GIC_SPI 25 IRQ_TYPE_LEVEL_HIGH>; 469 #address-cells = <1>; 470 #size-cells = <0>; 471 clock-names = "i2c"; 472 clocks = <&cru PCLK_I2C1>; 473 pinctrl-names = "default"; 474 pinctrl-0 = <&i2c1_xfer>; 475 status = "disabled"; 476 }; 477 478 i2c2: i2c@2005a000 { 479 compatible = "rockchip,rk3036-i2c", "rockchip,rk3288-i2c"; 480 reg = <0x2005a000 0x1000>; 481 interrupts = <GIC_SPI 26 IRQ_TYPE_LEVEL_HIGH>; 482 #address-cells = <1>; 483 #size-cells = <0>; 484 clock-names = "i2c"; 485 clocks = <&cru PCLK_I2C2>; 486 pinctrl-names = "default"; 487 pinctrl-0 = <&i2c2_xfer>; 488 status = "disabled"; 489 }; 490 491 uart0: serial@20060000 { 492 compatible = "rockchip,rk3036-uart", "snps,dw-apb-uart"; 493 reg = <0x20060000 0x100>; 494 interrupts = <GIC_SPI 20 IRQ_TYPE_LEVEL_HIGH>; 495 reg-shift = <2>; 496 reg-io-width = <4>; 497 clock-frequency = <24000000>; 498 clocks = <&cru SCLK_UART0>, <&cru PCLK_UART0>; 499 clock-names = "baudclk", "apb_pclk"; 500 pinctrl-names = "default"; 501 pinctrl-0 = <&uart0_xfer &uart0_cts &uart0_rts>; 502 status = "disabled"; 503 }; 504 505 uart1: serial@20064000 { 506 compatible = "rockchip,rk3036-uart", "snps,dw-apb-uart"; 507 reg = <0x20064000 0x100>; 508 interrupts = <GIC_SPI 21 IRQ_TYPE_LEVEL_HIGH>; 509 reg-shift = <2>; 510 reg-io-width = <4>; 511 clock-frequency = <24000000>; 512 clocks = <&cru SCLK_UART1>, <&cru PCLK_UART1>; 513 clock-names = "baudclk", "apb_pclk"; 514 pinctrl-names = "default"; 515 pinctrl-0 = <&uart1_xfer>; 516 status = "disabled"; 517 }; 518 519 uart2: serial@20068000 { 520 compatible = "rockchip,rk3036-uart", "snps,dw-apb-uart"; 521 reg = <0x20068000 0x100>; 522 interrupts = <GIC_SPI 22 IRQ_TYPE_LEVEL_HIGH>; 523 reg-shift = <2>; 524 reg-io-width = <4>; 525 clock-frequency = <24000000>; 526 clocks = <&cru SCLK_UART2>, <&cru PCLK_UART2>; 527 clock-names = "baudclk", "apb_pclk"; 528 pinctrl-names = "default"; 529 pinctrl-0 = <&uart2_xfer>; 530 status = "disabled"; 531 }; 532 533 i2c0: i2c@20072000 { 534 compatible = "rockchip,rk3036-i2c", "rockchip,rk3288-i2c"; 535 reg = <0x20072000 0x1000>; 536 interrupts = <GIC_SPI 24 IRQ_TYPE_LEVEL_HIGH>; 537 #address-cells = <1>; 538 #size-cells = <0>; 539 clock-names = "i2c"; 540 clocks = <&cru PCLK_I2C0>; 541 pinctrl-names = "default"; 542 pinctrl-0 = <&i2c0_xfer>; 543 status = "disabled"; 544 }; 545 546 spi: spi@20074000 { 547 compatible = "rockchip,rockchip-spi"; 548 reg = <0x20074000 0x1000>; 549 interrupts = <GIC_SPI 23 IRQ_TYPE_LEVEL_HIGH>; 550 clocks = <&cru PCLK_SPI>, <&cru SCLK_SPI>; 551 clock-names = "apb-pclk","spi_pclk"; 552 dmas = <&pdma 8>, <&pdma 9>; 553 dma-names = "tx", "rx"; 554 pinctrl-names = "default"; 555 pinctrl-0 = <&spi_txd &spi_rxd &spi_clk &spi_cs0>; 556 #address-cells = <1>; 557 #size-cells = <0>; 558 status = "disabled"; 559 }; 560 561 pdma: dma-controller@20078000 { 562 compatible = "arm,pl330", "arm,primecell"; 563 reg = <0x20078000 0x4000>; 564 interrupts = <GIC_SPI 0 IRQ_TYPE_LEVEL_HIGH>, 565 <GIC_SPI 1 IRQ_TYPE_LEVEL_HIGH>; 566 #dma-cells = <1>; 567 arm,pl330-broken-no-flushp; 568 arm,pl330-periph-burst; 569 clocks = <&cru ACLK_DMAC2>; 570 clock-names = "apb_pclk"; 571 }; 572 573 pinctrl: pinctrl { 574 compatible = "rockchip,rk3036-pinctrl"; 575 rockchip,grf = <&grf>; 576 #address-cells = <1>; 577 #size-cells = <1>; 578 ranges; 579 580 gpio0: gpio@2007c000 { 581 compatible = "rockchip,gpio-bank"; 582 reg = <0x2007c000 0x100>; 583 interrupts = <GIC_SPI 36 IRQ_TYPE_LEVEL_HIGH>; 584 clocks = <&cru PCLK_GPIO0>; 585 586 gpio-controller; 587 #gpio-cells = <2>; 588 589 interrupt-controller; 590 #interrupt-cells = <2>; 591 }; 592 593 gpio1: gpio@20080000 { 594 compatible = "rockchip,gpio-bank"; 595 reg = <0x20080000 0x100>; 596 interrupts = <GIC_SPI 37 IRQ_TYPE_LEVEL_HIGH>; 597 clocks = <&cru PCLK_GPIO1>; 598 599 gpio-controller; 600 #gpio-cells = <2>; 601 602 interrupt-controller; 603 #interrupt-cells = <2>; 604 }; 605 606 gpio2: gpio@20084000 { 607 compatible = "rockchip,gpio-bank"; 608 reg = <0x20084000 0x100>; 609 interrupts = <GIC_SPI 38 IRQ_TYPE_LEVEL_HIGH>; 610 clocks = <&cru PCLK_GPIO2>; 611 612 gpio-controller; 613 #gpio-cells = <2>; 614 615 interrupt-controller; 616 #interrupt-cells = <2>; 617 }; 618 619 pcfg_pull_default: pcfg-pull-default { 620 bias-pull-pin-default; 621 }; 622 623 pcfg_pull_none: pcfg-pull-none { 624 bias-disable; 625 }; 626 627 pwm0 { 628 pwm0_pin: pwm0-pin { 629 rockchip,pins = <0 RK_PA0 2 &pcfg_pull_none>; 630 }; 631 }; 632 633 pwm1 { 634 pwm1_pin: pwm1-pin { 635 rockchip,pins = <0 RK_PA1 2 &pcfg_pull_none>; 636 }; 637 }; 638 639 pwm2 { 640 pwm2_pin: pwm2-pin { 641 rockchip,pins = <0 RK_PA1 2 &pcfg_pull_none>; 642 }; 643 }; 644 645 pwm3 { 646 pwm3_pin: pwm3-pin { 647 rockchip,pins = <0 RK_PD3 1 &pcfg_pull_none>; 648 }; 649 }; 650 651 sdmmc { 652 sdmmc_clk: sdmmc-clk { 653 rockchip,pins = <1 RK_PC0 1 &pcfg_pull_none>; 654 }; 655 656 sdmmc_cmd: sdmmc-cmd { 657 rockchip,pins = <1 RK_PB7 1 &pcfg_pull_default>; 658 }; 659 660 sdmmc_cd: sdmmc-cd { 661 rockchip,pins = <1 RK_PC1 1 &pcfg_pull_default>; 662 }; 663 664 sdmmc_bus1: sdmmc-bus1 { 665 rockchip,pins = <1 RK_PC2 1 &pcfg_pull_default>; 666 }; 667 668 sdmmc_bus4: sdmmc-bus4 { 669 rockchip,pins = <1 RK_PC2 1 &pcfg_pull_default>, 670 <1 RK_PC3 1 &pcfg_pull_default>, 671 <1 RK_PC4 1 &pcfg_pull_default>, 672 <1 RK_PC5 1 &pcfg_pull_default>; 673 }; 674 }; 675 676 sdio { 677 sdio_bus1: sdio-bus1 { 678 rockchip,pins = <0 RK_PB3 1 &pcfg_pull_default>; 679 }; 680 681 sdio_bus4: sdio-bus4 { 682 rockchip,pins = <0 RK_PB3 1 &pcfg_pull_default>, 683 <0 RK_PB4 1 &pcfg_pull_default>, 684 <0 RK_PB5 1 &pcfg_pull_default>, 685 <0 RK_PB6 1 &pcfg_pull_default>; 686 }; 687 688 sdio_cmd: sdio-cmd { 689 rockchip,pins = <0 RK_PB0 1 &pcfg_pull_default>; 690 }; 691 692 sdio_clk: sdio-clk { 693 rockchip,pins = <0 RK_PB1 1 &pcfg_pull_none>; 694 }; 695 }; 696 697 emmc { 698 /* 699 * We run eMMC at max speed; bump up drive strength. 700 * We also have external pulls, so disable the internal ones. 701 */ 702 emmc_clk: emmc-clk { 703 rockchip,pins = <2 RK_PA4 2 &pcfg_pull_none>; 704 }; 705 706 emmc_cmd: emmc-cmd { 707 rockchip,pins = <2 RK_PA1 2 &pcfg_pull_default>; 708 }; 709 710 emmc_bus8: emmc-bus8 { 711 rockchip,pins = <1 RK_PD0 2 &pcfg_pull_default>, 712 <1 RK_PD1 2 &pcfg_pull_default>, 713 <1 RK_PD2 2 &pcfg_pull_default>, 714 <1 RK_PD3 2 &pcfg_pull_default>, 715 <1 RK_PD4 2 &pcfg_pull_default>, 716 <1 RK_PD5 2 &pcfg_pull_default>, 717 <1 RK_PD6 2 &pcfg_pull_default>, 718 <1 RK_PD7 2 &pcfg_pull_default>; 719 }; 720 }; 721 722 nfc { 723 flash_ale: flash-ale { 724 rockchip,pins = <2 RK_PA0 1 &pcfg_pull_default>; 725 }; 726 727 flash_bus8: flash-bus8 { 728 rockchip,pins = <1 RK_PD0 1 &pcfg_pull_default>, 729 <1 RK_PD1 1 &pcfg_pull_default>, 730 <1 RK_PD2 1 &pcfg_pull_default>, 731 <1 RK_PD3 1 &pcfg_pull_default>, 732 <1 RK_PD4 1 &pcfg_pull_default>, 733 <1 RK_PD5 1 &pcfg_pull_default>, 734 <1 RK_PD6 1 &pcfg_pull_default>, 735 <1 RK_PD7 1 &pcfg_pull_default>; 736 }; 737 738 flash_cle: flash-cle { 739 rockchip,pins = <2 RK_PA1 1 &pcfg_pull_default>; 740 }; 741 742 flash_csn0: flash-csn0 { 743 rockchip,pins = <2 RK_PA6 1 &pcfg_pull_default>; 744 }; 745 746 flash_rdn: flash-rdn { 747 rockchip,pins = <2 RK_PA3 1 &pcfg_pull_default>; 748 }; 749 750 flash_rdy: flash-rdy { 751 rockchip,pins = <2 RK_PA4 1 &pcfg_pull_default>; 752 }; 753 754 flash_wrn: flash-wrn { 755 rockchip,pins = <2 RK_PA2 1 &pcfg_pull_default>; 756 }; 757 }; 758 759 emac { 760 emac_xfer: emac-xfer { 761 rockchip,pins = <2 RK_PB2 1 &pcfg_pull_default>, /* crs_dvalid */ 762 <2 RK_PB5 1 &pcfg_pull_default>, /* tx_en */ 763 <2 RK_PB6 1 &pcfg_pull_default>, /* mac_clk */ 764 <2 RK_PB7 1 &pcfg_pull_default>, /* rx_err */ 765 <2 RK_PC0 1 &pcfg_pull_default>, /* rxd1 */ 766 <2 RK_PC1 1 &pcfg_pull_default>, /* rxd0 */ 767 <2 RK_PC2 1 &pcfg_pull_default>, /* txd1 */ 768 <2 RK_PC3 1 &pcfg_pull_default>; /* txd0 */ 769 }; 770 771 emac_mdio: emac-mdio { 772 rockchip,pins = <2 RK_PB4 1 &pcfg_pull_default>, /* mac_md */ 773 <2 RK_PD1 1 &pcfg_pull_default>; /* mac_mdclk */ 774 }; 775 }; 776 777 i2c0 { 778 i2c0_xfer: i2c0-xfer { 779 rockchip,pins = <0 RK_PA0 1 &pcfg_pull_none>, 780 <0 RK_PA1 1 &pcfg_pull_none>; 781 }; 782 }; 783 784 i2c1 { 785 i2c1_xfer: i2c1-xfer { 786 rockchip,pins = <0 RK_PA2 1 &pcfg_pull_none>, 787 <0 RK_PA3 1 &pcfg_pull_none>; 788 }; 789 }; 790 791 i2c2 { 792 i2c2_xfer: i2c2-xfer { 793 rockchip,pins = <2 RK_PC4 1 &pcfg_pull_none>, 794 <2 RK_PC5 1 &pcfg_pull_none>; 795 }; 796 }; 797 798 i2s { 799 i2s_bus: i2s-bus { 800 rockchip,pins = <1 RK_PA0 1 &pcfg_pull_default>, 801 <1 RK_PA1 1 &pcfg_pull_default>, 802 <1 RK_PA2 1 &pcfg_pull_default>, 803 <1 RK_PA3 1 &pcfg_pull_default>, 804 <1 RK_PA4 1 &pcfg_pull_default>, 805 <1 RK_PA5 1 &pcfg_pull_default>; 806 }; 807 }; 808 809 hdmi { 810 hdmi_ctl: hdmi-ctl { 811 rockchip,pins = <1 RK_PB0 1 &pcfg_pull_none>, 812 <1 RK_PB1 1 &pcfg_pull_none>, 813 <1 RK_PB2 1 &pcfg_pull_none>, 814 <1 RK_PB3 1 &pcfg_pull_none>; 815 }; 816 }; 817 818 uart0 { 819 uart0_xfer: uart0-xfer { 820 rockchip,pins = <0 RK_PC0 1 &pcfg_pull_default>, 821 <0 RK_PC1 1 &pcfg_pull_none>; 822 }; 823 824 uart0_cts: uart0-cts { 825 rockchip,pins = <0 RK_PC2 1 &pcfg_pull_default>; 826 }; 827 828 uart0_rts: uart0-rts { 829 rockchip,pins = <0 RK_PC3 1 &pcfg_pull_none>; 830 }; 831 }; 832 833 uart1 { 834 uart1_xfer: uart1-xfer { 835 rockchip,pins = <2 RK_PC6 1 &pcfg_pull_default>, 836 <2 RK_PC7 1 &pcfg_pull_none>; 837 }; 838 /* no rts / cts for uart1 */ 839 }; 840 841 uart2 { 842 uart2_xfer: uart2-xfer { 843 rockchip,pins = <1 RK_PC2 2 &pcfg_pull_default>, 844 <1 RK_PC3 2 &pcfg_pull_none>; 845 }; 846 /* no rts / cts for uart2 */ 847 }; 848 849 spi-pins { 850 spi_txd:spi-txd { 851 rockchip,pins = <1 RK_PD5 3 &pcfg_pull_default>; 852 }; 853 854 spi_rxd:spi-rxd { 855 rockchip,pins = <1 RK_PD4 3 &pcfg_pull_default>; 856 }; 857 858 spi_clk:spi-clk { 859 rockchip,pins = <2 RK_PA0 2 &pcfg_pull_default>; 860 }; 861 862 spi_cs0:spi-cs0 { 863 rockchip,pins = <1 RK_PD6 3 &pcfg_pull_default>; 864 865 }; 866 867 spi_cs1:spi-cs1 { 868 rockchip,pins = <1 RK_PD7 3 &pcfg_pull_default>; 869 870 }; 871 }; 872 }; 873};
